Sizes: 2″ – 48″ or DN 50 – DN 1200
Pressure Rating: Class150 or PN6 – PN16
Materials of valve body: WCB, LCB, WC6, CF8, CF3, CF8M, CF3M, 4A, etc.
Operation: Manual, Gear, Pneumatic, hydraulic and Electric actuator
Features
Bi-direction design
Replaceable Rubber seat, Bubble-tight seat seal
Self-cleaning mechanism
Rising stem or Non-rising stem
Wafer Lugged body
Design & Manufacture:
MSS SP-61, ASME 16.34
Face to Face: MSS SP-81, ASME B16.10, EN 558
Connection End: ASME B16.5, EN 1092, JIS B2220
Test : MSS SP-81
